| Machine Capacity |
: |
Outside ø230mm and Length 350mm |
| Machine Control |
: |
Computerized Numeric Control (CNC) |
| Spindle Size & Type |
: |
A2-8 Cartridge type Spindle with Angular Contract Bearing |
| Spindle Speed & Power |
: |
Veriable up to 1800 r.p.m. & 11Kw ( 15 HP ) |
| Axis Type |
: |
Simultaneously controlled tow Asex, Highly rigid Roller type LM Guideways with Precision Ground Ballscrew moving by AC Servo Motors |
| Tooling |
: |
Machine is equipped with 8-station Indexing Bi-directional Vertical Tool Turret |
| Machine Lubrication |
: |
Automactic Centralized Oil Lubrication System |
| Job Clamping |
: |
Hydraulically operated Expanding Collet with rotary cylinder. |
| Coolant |
: |
Machine is equipped with Cold Air Gun which converts Normal compressed air into Freezing cold air |
