| Machine Capacity |
: |
Bore range ø85mm to ø140mm and Length 350mm |
| Machine Control |
: |
PLC withTouch Panel HMI |
| Spindle Type |
: |
Vetical Carriage mounted Extension Spindle |
| Spindle Speed & Power |
: |
Veriable up to 2500 r.p.m. & 3.7Kw ( 5 HP ) |
| Axis Type |
: |
Highly rigid Roller type LM Guideways with Precision Ground Ballscrew moving by AC Servo Motor |
| Machine Lubrication |
: |
Automactic Centralized Oil Lubrication System |
| Job Clamping |
: |
Specially Designed Pneumatic operated Fixture having upper Swing clamp for Liner coller clamping and lower multipoint Clamp |
| Fine Boring Head |
: |
SECO make Fine Boring Head with micro setting tool cartridge |
